Trailed Stiletto Powerhead 2000L Sprayer

Trailed air assist Stiletto 2000 litre sprayer with 161L/min diaphragm pump, electric controls, a Glideflex axle upgrade, wide angle shaft and Powerhead conveyor with 920mm fan. Ideal for orchards with trees up to 5 metres high. Additional model available with Bravo 180S automatic rate controller (DST23PB8G).

Product Code: DST23PF8G

Trailed Stiletto Powerhead 2000L Sprayer

specifications

Market:

Horticulture

Tank Size (L):

2000

Connection Type:

Trailed

Min PTO HP:

60

Pump Size (L/min):

161

Height / Width / Length (MM):

1500 / 1700 / 4100

Product Weight (KG):

680

Application:

Orchards.

Request More Information

    Find Your Nearest Dealer

    Key Features

    Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifolds. IDS1701: 161L/min. capacity 5000kPa pressure.

    920mm axial flow type, 10 bladed fan with curved nylon reinforced blades, centrifugal clutch for soft engagement/disengagement and protective mesh cover.

    24 flip-over nozzle bodies for dilute/concentrate spraying with on/off. 12 ceramic hollow cone nozzles per side and 12 ceramic jets with stainless steel swirl-plates per side.

    40 bar electric section valves, master valve, electric pressure adjustment and in cab control.

    Galvanised steel with jockey wheel and adjustable drawbar.

    Factory Options

    Leaf guard (to suit Powerhead) (D99-175)

    Twin nozzles (includes extra nozzles) (D99-182)

    Flotation tyres - 400/60 x 15.5” with fixed axle (in lieu of standard singles) (D99-80)

    Note: Not all options will fit all models.Extra charges may apply to fitment of some options.

    Additional model available with Bravo 180S automatic rate controller (DST23PB8G).
